ON Semiconductor . NXH40T120L3Q1SG
IGBT Module Three Phase Chassis Mount
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Brand | ON Semiconductor |
|---|---|
| DimensionUnit | mm |
| height | 12.5 |
| height_Attrib | Height |
| jsonUrlData | 1958775 |
| length | 83.0 |
| length_Attrib | Length |
| moq, multiple, tierMinQty1 | 1 |
| MPN | NXH40T120L3Q1SG |
| SKU | 195-8775 |
| tierMinQty2 | 2 |
| tierMinQty3 | 5 |
| tierMinQty4 | 10 |
| tierMinQty5 | 15 |
| tierPrice1 | 56.96 |
| tierPrice2 | 54.12 |
| tierPrice3 | 51.26 |
| tierPrice4 | 48.42 |
| tierPrice5 | 47.27 |
| width | 37.9 |
| width_Attrib | Width |
| Maximum Operating Temperature | +175 °C |
| Length | 83mm |
| Maximum Collector Emitter Voltage | 1200 V |
| Package Type | Q13-TNPC |
| Maximum Power Dissipation | 145 W |
| Mounting Type | Surface Mount |
| Minimum Operating Temperature | -40 °C |
| Width | 37.9mm |
| Height | 12.5mm |
| Pin Count | 44 |
| Dimensions | 83 x 37.9 x 12.5mm |
| Maximum Gate Emitter Voltage | ±20V |
| Channel Type | N |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| 195-8775 | 1 | 1 | 1 @ $56.96, 2 @ $54.12, 5 @ $51.26, 10 @ $48.42, 15 @ $47.27 | ||
 Newark | 41AH2126 | 1 | 18 | 1 | 1 @ $343.25 |
| RS Delivers | 195-8774 | 1 | 21 | 1 | 1 @ $214.78 |
 Digi-Key | 10670083 | 1 | 1 | 1 @ $419.59, 21 @ $401.86 | |
| Newark | 38AH7360 | 1 | 1 |
