AUTONICS TX4H-24R | Module: regulator; temperature; SPST-NO; OUT 2: alarm; OUT 3: alarm

Autonics TX4H-24R -LCD Display PID Temperature ControllersTX Series 50ms high-speed sampling rate and +-0.3% display accuracy Large LCD display with easy-to-read white PV characters Switch between current output and SSR drive output SSR drive output (SSRP function) control options : ON/OFF control, cycle control, phase control Communication output model available : RS485 (Modbus RTU) Parameter configuration via PC (RS485 communication) : DAQMaster software included (comprehensive device management software) Compact, space-saving design with 45mm depth : 30% rear-length size reduction compared to similar-sized (48x48mm) models from AutonicsThe TX series temperature controllers feature easy-to-read LCD displays with large, white PV characters. The 11-segment displays used for PV and SV are useful for displaying various alphanumeric characters and provide improved legibility. The temperature controllers also feature 50 ms high-speed sampling cycle and +-0.3% display accuracy. The space-saving design with 45 mm depth allows easy installation in limited spaces (DIN 48 x 48 mm models). The TX series can be configured and monitored on PCs via USB or RS485 communication, and are available in diverse sizes for flexible installation in various environments.50ms High-Speed Sampling Cycle50ms high-speed sampling rate allows accurate temperature control in applications requiring fast response speeds.SSR Drive Output (SSRP Function) Control OptionsUsers can select from ON/OFF control, cycle control, and phase control using standard SSR drive output option. Precise and accurate control is possible at low costs.Ordering Information
