Contactor, Definite Purpose, 25A, 2 pole, 5 HP at 230 VAC, 1 phase, 277 VAC 60 Hz coil, open | Mayer Electric

Mayer Electric Supply . 8910DPA22V04

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
Extra Product NameContactor, Definite Purpose, 25A, 2 pole, 5 HP at 230 VAC, 1 phase, 277 VAC 60 Hz coil, open | Mayer Electric
UPC785901024347
jsonUrlData/Product/SQUARE-D-Contactor-Definite-Purpose-25A-2-pole-5-HP-at-230-VAC-1-phase-277-VAC-60-Hz-coil-open-785901024347
jsonUrlData2c96fa654-11e3-437b-9216-abd200613fe5
moq, multiple, tierMinQty11
MPN8910DPA22V04
qtyInStock0
SKUSQD8910DPA22V04
tierPrice182.85
Range Of ProductDPA
Poles Description2P
Line Rated Current25 A
Product Or Component TypeDefinite Purpose Contactor
Pole Contact Composition2 NO
Warranty18 months
[Uc] Control Circuit Voltage277 V AC 60 Hz
Locked Rotor Rated Current125 A 460 V AC || 100 A 575 V AC || 150 A 277 V AC
Maximum Horse Power Rating2-2 hp 115 V AC, 1 phase || 5-5 hp 230 V AC, 1 phase
Electrical Connectionbinder head || quick connect terminals
Phase1 phase
[Ue] Rated Operational Voltage600 V AC
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information, Mercury FreeYes
Eu Rohs DirectiveCompliant
Reach RegulationReference contains Substances of Very High Concern above the threshold
Product CertificationsUL Recognized || CSA

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQD8910DPA22V04111 @ $82.85
