Jobber Length Drill Bit, Drill Bit Size 19/64 in, Drill Bit Point Angle 118 Degrees , Vanadium High Speed Steel, TiCN, Decimal Equivalent 0.2969, Fractional Inch, Drill Bit Point Type Conventional Point, Non-Coolant Through, Number of Coolant Holes 0
Jobber Length Drill Bit, Drill Bit Size 19/64 in, Drill Bit Point Angle 118 Degrees , Vanadium High Speed Steel, TiCN, Decimal Equivalent 0.2969, Fractional Inch, Drill Bit Point Type Conventional Point, Non-Coolant Through, Number of Coolant Holes 0
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Zoro | G0972428 | 1 | 1 | 1 @ $47.34 | |
 Megadepot | C73019 | 1 | 1 | 1 @ $9.45 | |
| sustainablesupply.com | C2767904 | 1 | -2 | 1 | 1 @ $11.55 |
| C73019 | 1 | -2 | 1 | 1 @ $9.52 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Cleveland 2002G-TC Style High Speed Steel Jobbers' Drill Bit, TiCN Coated, Round Shank,118 Degree Point, 19/64" Size, 6-Pack
Brand: Cleveland
Details
- High-speed steel (HSS) containing vanadium is a good combination of toughness and high red hardness, for use on drilling through hard substances
- Titanium carbonitride (TiCN) is harder than TiN, to help provide heat resistance for more abrasive materials
- 118-degree with improved geometry, for performance in general drilling applications
- Jobber-length, for a wide range of applications
- Round shanks, for use with a variety of tool holders
- Made in the USA
Cleveland 2002G-TC Style High Speed Steel Jobbers' Drill Bit, TiCN Coated, Round Shank,118 Degree Point, 19/64" Size, 6-Pack
Brand: CLEVELAND
Details
- Decimal equivalent .2969, flute length 3.063", overall length 4.375"
- Titanium carbonitride (TiCN) coatings are harder and more wear-resistant than TiN for improved tool life and faster cutting speeds
- High-speed steel tools are good for most general purpose applications, offering a combination of hardness and toughness for wear resistance
- Round shanks allow use with a wide variety of toolholding systems
- When run in a counterclockwise direction (right-hand cut) spiral fluted tools evacuate chips up and out of the cut to reduce clogging
- Made in the USA
19/64 (6 Pieces)
Brand: CLEVELAND
'Jobber Drill Bit, Fractional Inch, Drill Bit Size 19/64 In., Decimal Equivalent 0.2969, Drill Bit Point Angle 118 Degrees , Drill Bit Material High Speed Steel, Drill Bit Finish TiCN, Shank Type Straight, Flute Type Spiral, Coolant Fed Non-Coolant Through, Cutting Direction Right Hand, Overall Length 4-3/8 In., Grade General Purpose, Shank Dia. 19/64 In., Flute Length 3-1/16 In., Point Type Radial, List Number 2002G-TC, Standards ASME B94.11M-1993'
Details
- Price For: Pack of 6 Decimal Equivalent : 0.2969 List Number : 2002G-TC Drill Bit Point Angle : 118 Degrees Coolant Through : No Drill Bit Grouping : Drill Bit Point Type : Radial Shank Type : Straight Drill Bit Size : 19/64" Application : For Steel, Stainless Steel, Cast Iron, Non-Ferrous Metals, High-Temperature Alloys, Titanium Alloys and Hard Materials Overall Length : 4-3/8"
- Drill Bit Dimension Type : Fractional Inch Drill Bit Finish : TiCN Standards : ASME B94.11M-1993 Item : Jobber Length Drill Bit Material : High Speed Steel Flute Length : 3-1/16" Finish : Tin Flute Type : Spiral Drill Bit Material : High Speed Steel Shank Dia. : 0.2969" Grade : General Purpose Number of Flutes : 2 Cutting Direction : Right Hand Depth x Dia. Ratio : 4xD Shank Size : 0.2969
- Left/Right Hand : Right Point Angle : 118 Diameter : 0.296875 Drill Style : Jobber Drill Shank Length : 1-5/16" Measurement System : Fractional Inch Depth:Dia. Ratio : 4xD Coolant Fed : Non-Coolant Through Helix Angle : 21 Degrees to 34 Degrees Primary Material Application : Aluminum, Brass, Bronze, Copper, Stainless Steel, Steel Material Grade - Machining : General Purpose Primary Material Application ISO Code : M, N, P
- Series : 2002G-TC Drill Diameter Tolerance : +0.0000"/-0.0010" Shank Type - Machining : Straight Finish - Machining : TiCN Drill Bit Point Type : Conventional Point Drill Length Class : Jobber Length Material - Machining : Vanadium High Speed Steel Spiral Direction : Right Hand Maximum Drilling Depth : 1-3/16" Drill Point Length : 0.0892" Country of Origin (subject to change) : United States
Listing
| Product group | BISS Basic |
|---|---|
| Product type | ELECTRONIC_COMPONENT |
| Part number | C73019 |
| Items per pack | 6 |
| Label | CLEVELAND |
| Manufacturer | CLEVELAND |
