Hamilton

Hamilton . R-FMK-63HMB

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameHamilton
DimensionUnitinch
GraingerSku55GZ78
UnitOfMeasureEA
Weight21
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginUS
extendedLead20
extendedQty-2
height6
jsonUrlData924526ffbdad25e5923b
length, width10
moq, multiple, tierMinQty1, Number of Wheels1
MPNR-FMK-63HMB
qtyInStock0
qtyInStockOverrideDrop Ship
SKUG9075234
tierPrice1291.71
urlhttps://www.zoro.com/hamilton-plate-caster-1000-lb-load-rating-r-fmk-63hmb/i/G9075234/
Caster Sub-TypeRigid
Load Rating1000 lb
Wheel Dia6 in
Wheel Width, Overall Wheel Width3 in
Caster Frame MaterialSteel
Tread ShapeStandard
Outside Bolt Hole Spacing3-3/8 in x 5-1/4 in
Wheel/Tread Hardness188 BHN
Wheel TypeFlat-Free
With Toe Plate, NSF Listed, Includes Thread Guards, Leveling Caster, Non-Marking, Includes Mounting FastenersNo
Frame ColorBlack
Mounting Plate Size4 1/2 in x 6 1/2 in
Mounting Plate Thickness5/16 in
Caster Mounting TypePlate
TreadFlat
Wheel/Tread Material, Wheel Core MaterialCast Iron
Wheel/Tread Hardness RatingExtra Hard
Tire StyleTubeless
For Surface TypeConcrete
Wheel Bearing TypePrecision Ball
Swivel ConstructionKingpinless
Swivel Lock TypeNo Lock Included
StandardsICWM
Swivel Lead1 3/4 in
Mounting Height7 1/2 in
ApplicationAerospace Tooling, All Purpose Industrial/Commercial Casters, Automotive Assembly Lines, Body Dolly Carts, Chassis Rack Carts, Engine Dollies, Material Carts
Inside Bolt Hole Spacing2-7/16 in x 4-15/16 in
Caster Product GroupRigid Caster
Load Rating Range1000 to 2999 lb
Swivel Bearing Seal TypeSealed
ItemHeat-Resistant Standard Plate Caster
Frame ConstructionForged
For Axle Dia3/4 in
Swivel RadiusNone- Rigid Caster
Frame FinishEnamel
Core Color, Wheel/Tread ColorSilver
Operating Temperature Range-50 Degrees to 200 Degrees F
SeriesMagmaMax
Includes Spanner Bushing, ESD ConductiveYes
Swivel Raceway TypeRoller
Wheel Core TypeSolid
FeaturesDurable, High Heat, Quiet Operation, Reliable
Wheel Bearing MaterialStainless Steel
Number of Mounting Holes4
Mounting Plate Bolt Hole PatternA
Mounting Bolt Dia1/2 in
Caster Brake TypeNo Brake Included
Country of Origin (subject to change)United States

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG9075234111 @ $291.71
Grainger55GZ7811
