| Brand name, Manufacturer name, Manufacturer | NOSHOK |
|---|
| Extra Product Name | SunSource | 25-1012-P25-A2P-1-SL NOSHOK Industrial Hydraulics | SunSource.com |
|---|
| jsonUrlData | e2f24e4a-8ef0-4c43-a450-ae640030d6a9 |
|---|
| keywords | 1000 Series 0 to 25 psid Range Piston Type Differential Pressure Gauge 25-1012-P25-A2P-1-SL |
|---|
| moq, multiple, tierMinQty1, Syndication, Unit | 1 |
|---|
| MPN, SKU | 25-1012-P25-A2P-1-SL |
|---|
| qtyInStock | 0 |
|---|
| snippet | 25-1012-P25-A2P-1-SL NOSHOK | Search our online catalog of Industrial Hydraulics. Start your quote online to connect with our team of technical experts for support. |
|---|
| tierPrice1 | 490.42 |
|---|
| 1000 Series Piston Type Differential Gauges Switch or Transmitter Type and Housing | Single SwitchDual Switch4-20 mA Transmitter |
|---|
| 3-Valve Differential Pressure Manifold Valves | NOSHOK`s 3-Valve Differential Pressure Manifold Valves are available in Hard Seat & Soft Seat, and Hard Seat & Soft Tip. |
|---|
| Alternating Current (AC) Voltage, Direct Current (DC) Voltage | 125 |
|---|
| Ambient Temperature Range (4-20 mA Transmitter Option) | -20 to 150 |
|---|
| Ambient Temperature Range (Switch Option), Media Temperature Range (Switch Option) | -40 to 200 |
|---|
| Application | Back flow testingHeat exchangersFilter monitoringFlow indicationLevel indication |
|---|
| Bezel Material, Material | Engineered Plastic |
|---|
| Category | 1000 Series Piston Type Differential Pressure Gauges |
|---|
| Connection Location | Back |
|---|
| Connection Size | 1/4 |
|---|
| Connection Type | Female National Pipe Thread (FNPT) |
|---|
| Current Rating | 0.25 |
|---|
| Dial/Display Size | Aluminum, white background with black scale. |
|---|
| Fill Fluids (Optional) | Silicone (Optional Silicone filling available with 2-1/2" and 6" gauge case sizes, and 4-1/2" gauge case size with aluminum case and standard shatter-resistant acrylic lens only.) |
|---|
| Full Scale on Rising Pressure Accuracy () | 3/2/3 |
|---|
| Gauge Size | 2-1/2|6 |
|---|
| Lens/Display Material | Shatter-Resistant Acrylic |
|---|
| Measuring Element | 316 stainless steel and ceramic piston/magnet |
|---|
| Movement | Magnetic |
|---|
| Note | SPDT, 3W, 0.25 Amp, 125 Vac/Vdc (standard) (switch adjustable range of 15-95%). Other options available, consult factory. |
|---|
| Operating Temperature [Max] | 93 |
|---|
| Operating Temperature [Min] | -40 |
|---|
| Options and Accessories | (2) 1/4 20 Mounting Holes (MH)Pipe Mounting Kit, Steel (MK5 CS)Pipe Mounting Kit, Stainless steel (MK5 SS)Reversed Ports (RP)Stainless Steel Tagging (ST)Wall Mounting Kit (WMK) |
|---|
| O-Ring and Diaphragm Materials | Fluoroelastomer (FKM) |
|---|
| Pointer | Balanced Aluminum, Black Finish |
|---|
| Power Rating | 3 |
|---|
| Pressure Range | 0 to 25 |
|---|
| SchemaID | 101737 |
|---|
| Sensor Housing Materials | Aluminum |
|---|
| Series | 1000 |
|---|
| Switch Rating | Single Pole Double Throw (SPDT) |
|---|
| Type | Differential Pressure Gauge |
|---|
| Working Pressure [Max] | 3,000 |
|---|
| Price: | $490.42 |
|---|
