Reversing Starter TeSys Hybrid Safe-Torque-Off 3kW-400V control 24VDC | Mayer Electric

Mayer Electric Supply . LZ8H6X5BD

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitmm
Extra Product NameReversing Starter TeSys Hybrid Safe-Torque-Off 3kW-400V control 24VDC | Mayer Electric
UPC785901476245
Weight212
WeightUnitg
Weight_AttribNet Weight
depth, length114.5
height99.0
height_AttribHeight
jsonUrlData/Product/SCHNEIDER-ELECTRIC-Reversing-Starter-TeSys-H-Safe-Torque-Off-3kW-400V-control-24VDC-785901476245
jsonUrlData2d98feb69-0f73-4d8d-9f90-abd20062793e
length_AttribDepth
moq, multiple, tierMinQty11
MPNLZ8H6X5BD
qtyInStock0
SKUSQDLZ8H6X5BD
tierPrice1387.94
width22.5
width_AttribWidth
[Uc] Control Circuit Voltage24 V DC
[Ue] Rated Operational Voltage500 V AC
Thermal Protection Adjustment Range1.5-9 A
Product Or Component Typereversing ultra-compact starter
Product NameTeSys Hybrid
Thermal Overload Classclass 10A IEC 60947-4-2
Motor Power Kw1.5 kW 220 V AC 0.65 || 1.5 kW 230 V AC 0.65 || 2.2 kW 380 V AC 0.65 || 3 kW 400 V AC 0.65 || 3 kW 415 V AC 0.65 || 3 kW 440 V AC 0.65 || 3 kW 500 V AC 0.65
RangeTeSys
Motor Starter Typedirect on line
[Ie] Rated Operational Current6.5 A 500 V AC-53A || 9 A 500 V AC-51 || 5 A 500 V AC-53A mounting side by side || 7 A 500 V AC-51 mounting side by side
Poles Description3P
Safety Reliability DataMTTFd = 517 years stop function || PFHd = 2.67E-9 1/h stop function || SFF = 99 % stop function || SFF = 99 % motor protection || MTTFd = 447 years motor protection
Maximum Horse Power Rating1 hp 200 V AC || 1.5 hp 230 V AC || 3 hp 460 V AC
Device Short NameLZ8H
Safety LevelSIL 3 IEC 61508-1 stop function || PL = e ISO 13849-1 stop function || SIL 2 IEC 61508-1 motor protection
Height99 mm
Resetmanual || electrical reset
StandardsUL 60947-4-1 || IEC 60947-4-2
Mounting SupportDIN rail
Pollution Degree2
Net Weight212 g
[Uimp] Rated Impulse Withstand Voltage6 kV
Connections - Terminalsscrew clamp terminals 1 0.2-2.5 mm? rigid || screw clamp terminals 1 0.25-2.5 mm? flexible - with cable end || screw clamp terminals 1 0.2-2.5 mm? flexible - without cable end
[Ui] Rated Insulation Voltage500 V AC 50/60 Hz
Mounting Modeby clips
Maximum Operating Rate120 cyc/mn AC-51 50 % || 6 cyc/mn AC-53A 50 %
Auxiliary Contact Composition1 C/O fault signalling
Control Circuit Voltage Limits19.2...30 V DC
CertificationsATEX as associated device for motor protection in zones 1 and 21 || CE || cULus
Width22.5 mm
Tightening Torque0.5-0.6 N.m flat ? 2.5 mm 3 mm
Depth114.5 mm
Electrical Durability30 Mcycles
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal Free, Reach Free Of SvhcYes
Environmental DisclosureENVPEP1509013EN
Sustainable Offer StatusGreen Premium product
Reach RegulationFree of Substances of Very High Concern above the threshold
California Proposition 65 : WARNINGCancer and Reproductive Harm - www.P65Warnings.ca.gov
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs RegulationX
Circularity ProfileENVEOLI1509013EN
Eu Rohs DirectiveCompliant
Ambient Air Temperature For Operation-25-30 ?C without derating || 30-70 ?C with derating
Ambient Air Temperature For Storage-40-80 ?C
Protective TreatmentTC
Ip Degree Of ProtectionIP20

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDLZ8H6X5BD111 @ $387.94
