OA172EC-22-1TBIP68A Orion Fans | Fans, Thermal Management | DigiKey
Fan Tubeaxial 230VAC Rectangular/Rounded - 172mm L x 150mm H Ball 220.0 CFM (6.16m?/min) 2 Terminals
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Orion Fans |
|---|---|
| CategoryL1, Category | Fans, Thermal Management |
| CategoryL2 | Fans |
| CategoryL3 | AC Fans |
| DimensionUnit | mm |
| Extra Product Name | OA172EC-22-1TBIP68A Orion Fans | Fans, Thermal Management | DigiKey |
| Weight | 1.5 |
| WeightUnit | lbs |
| Weight_Attrib | Weight |
| atoms, moq, multiple, tierMinQty1 | 1 |
| extraShipping | 0 |
| MPN, Manufacturer Product Number | OA172EC-22-1TBIP68A |
| packaging, Package | Box |
| qtyInStock | 20 |
| SKU | 9380241 |
| snippet, Detailed Description | Fan Tubeaxial 230VAC Rectangular/Rounded - 172mm L x 150mm H Ball 220.0 CFM (6.16m?/min) 2 Terminals |
| tierMinQty2 | 10 |
| tierMinQty3 | 25 |
| tierMinQty4 | 50 |
| tierPrice1 | 127.70000 |
| tierPrice2 | 114.77200 |
| tierPrice3 | 113.15520 |
| tierPrice4 | 105.88080 |
| width | 51.0 |
| width_Attrib | Width |
| Digi-Key Part Number | 1053-1822-ND |
| Description | FAN 172X150X51MM 230VAC IP68ATEX |
| Manufacturer Standard Lead Time | 19 Weeks |
| Series, Base Product Number | OA172EC |
| Product Status | Active |
| Voltage - Rated | 230VAC |
| Size / Dimension | Rectangular/Rounded - 172mm L x 150mm H |
| Width | 51.00mm |
| Air Flow | 220.0 CFM (6.16m?/min) |
| Static Pressure | 0.620 in H2O (154.4 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Electronic Commutation (EC), Thermal Overload Protector (TOP) |
| Noise | 57.0dB |
| Power (Watts) | 15.00W |
| RPM | 3000 RPM |
| Termination | 2 Terminals |
| Ingress Protection | IP68 - Dust Tight, Waterproof |
| Operating Temperature | -4 ~ 158?F (-20 ~ 70?C) |
| Approval Agency | ATEX, CE, cURus, UR |
| Current Rating (Amps) | 0.130A |
| Voltage Range | 207 ~ 253VAC |
| Material - Frame | Aluminum |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp | 50000 Hrs @ 40?C |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 9380241 | 1 | 20 | 1 | 1 @ $127.70, 10 @ $114.77, 25 @ $113.16, 50 @ $105.88 |
 Newark | 91AH9592 | 1 | 1 | 1 @ $137.25, 5 @ $133.44, 10 @ $126.58, 25 @ $118.19, 50 @ $111.33, 100 @ $103.70 | |
| 10142348 | 1 | 1 | 1 @ $127.10 | ||
| us.rs-online.com | 71443204 | 1 | 2 | 1 | 1 @ $127.74, 10 @ $114.81, 25 @ $113.19, 50 @ $105.91, 100 @ $103.50 |
 Newark | 51AK1514 | 1 | 6 | 1 | 1 @ $130.87, 5 @ $123.31, 10 @ $118.01, 25 @ $112.71, 50 @ $109.69, 100 @ $105.91 |
