Grundfos 96081984 CR 1-11 A-B-A-E-HQQE 3PH 1.5HP TEFC 60HZ - MROSupply.com

The 96081984 is produced by Grundfos and is described as a Grundfos 96081984 CR 1-11 A-B-A-E-HQQE 3PH 1.5HP TEFC 60HZ

Grundfos . 96081984

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Brand, Label, Man, Publisher, StudioGrundfos
CategoryL1Pumps
CategoryL2Centrifugal Pumps
CategoryL3Chemical Resistant
Extra Product NameGrundfos 96081984 CR 1-11 A-B-A-E-HQQE 3PH 1.5HP TEFC 60HZ - MROSupply.com
moq, multiple, tierMinQty1, Case, NumberOfItems, Number_of_items1
MPN, Part Number, Product no, Keyword, PartNumber, Part_number, Sku96081984
qtyInStock, Number of reduced-diameter impellers0
SKU5023256
snippetThe 96081984 is produced by Grundfos and is described as a Grundfos 96081984 CR 1-11 A-B-A-E-HQQE 3PH 1.5HP TEFC 60HZ
tierPrice11895.56
EAN, EANList, Identifier5700395167221
Product GroupBISS
Max ambient temperature (F)140
Temperature range (F)-4 - 248
Density (lb/ftBi)62.29
Rated voltage3 x 208-230YY/460Y V
HP1.5
Max pressure (psi)232
Pipe connection1 in NPT
Stages, Impellers11
Flange size, Flange size for motor56C
Rate flow (gpm)9.69
Density998.2 kg/m?
Rated speed3440-3480 RPM
Power (P2) required by pump, Rated power - P21.1 kW
Mains frequency60 Hz
Pump version, Model, Material codeA
Pumped liquidWater
Product nameCR 1-11 A-B-A-E-HQQE
Pressure rating for connectionPN 16
Motor efficiency at 3/4 load83.5-81.0 %
Rated head74.5 m
Approvals for drinking waterNSF/ANSI 61
IE Efficiency classNEMA Premium / IE3 60Hz
Insulation class (IEC 85)F
Size of outlet connection, Size of inlet connection1 in
Temperature (?C)16 bar / -20
Max pressure at stated temp (?C)16 bar / 120
Motor no98976607
ApprovalsCURUS
Starting current720 %
Rated flow2.2 m?/h
Full load SF current5,1-4,95/2,48 A
Motor standardNEMA
Motor efficiency at full load84.1-83.5 %
BaseCast iron
Shaft seal arrangementSingle
Pump orientationVertical
Type of connectionOval / NPT(F)
Maximum operating pressure (bar)16
Low NPSHN
Selected liquid temperature (?C)20
Connect codeB
Curve tolerance2012 3B
Cos phi - power factor0.84-0.78
Service factor1.15
Number of poles2
Pump speed on which pump data are based3466 RPM
Maximum head98.7 m
BearingSIC
Liquid temperature range (?C)-20 - 120
Motor type80CA
Code for shaft sealHQQE
CoolingTEFC
ImpellerStainless steel
Code for rubberE
Maximum ambient temperature (?C)60
Rated current4,45-4,3/2,16 A
Motor efficiency at 1/2 load82.0 %
Enclosure class (IEC 34-5)55 Dust/Jetting
ASIN, AsinB00LBHOIEA
AdultProduct, Autographed, Memorabilia, TradeInEligibleFalse
Bullet_pointBrand: Grundfos Category: HVAC Free Shipping on this item! Product Number: 96081984 U-A-A-E-HQQE 3ph 1.5HP TEFC 60Hz 96081984
CatIndustrial & Scientific
CatId16310091
CatTree16310091 16310161 256346011
ClassificationId720590011
DisplayNameHVAC Equipment
FeatureBrand: Grundfos
Height192 29
IdentifierTypeEAN
ItemClassificationBASE_PRODUCT
ItemName, Item_name, TitleGrundfos 96081984
Item_type_keywordindustrial-hvac-components
Linkhttps://m.media-amazon.com/images/I/31fXl73p9BL._SL75_.jpg https://m.media-amazon.com/images/I/31fXl73p9BL.jpg
ProductGroupBISS BISS Basic
ProductType, ProductTypeNameMECHANICAL_COMPONENTS
Product_descriptionGrundfos 96081984. U-A-A-E-HQQE 3ph 1.5HP TEFC 60Hz 96081984
Product_site_launch_date2014-06-26T21:19:58.690Z
Typeean
URLhttp://ecx.images-amazon.com/images/I/31fXl73p9BL._SL75_.jpg https://m.media-amazon.com/images/I/31fXl73p9BL._SL75_.jpg
Unitspixels pounds
VariantMAIN
WebsiteDisplayGroupbiss_basic_display_on_website
WebsiteDisplayGroupNameBISS Basic
Weight0.000625
Width500 75

Distributor offers

SellerSKUMOQIn stockMultiplePrices
MRO Supply5023256111 @ $1895.56
PlumbersStock423790111 @ $1555.33
pumpproducts.com960819841(Usually Ships 7-10 Days)11 @ $2664.00
Edge Supply960819841-211 @ $2333.00
