motion servo drive, Lexium 28, sercos, single and three phase 200...230 V, 200 W | Mayer Electric

SQUARE D . SQDLXM28SU02M3X

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
DimensionUnitmm
Extra Product Namemotion servo drive, Lexium 28, sercos, single and three phase 200...230 V, 200 W | Mayer Electric
UPC, MPN, SKUSQDLXM28SU02M3X
Weight, moq, multiple, tierMinQty11
WeightUnitkg
Weight_AttribNet Weight
depth, length146.0
height150.0
height_AttribHeight
jsonUrlData/Product/SQUARE-D-motion-servo-drive-Lexium-28-sercos-single-and-three-phase-200-230-V-200-W-SQDLXM28SU02M3X
jsonUrlData226388765-760f-43d9-bf97-aeea005673c7
length_AttribDepth
qtyInStock0
tierPrice10.0
width55.0
width_AttribWidth
Line Current2.4 A 226.8 % 220 V, single phase || 2.4 A 200.7 % 220 V, three phase
Range Of ProductLexium 28
Format Of The Drivecompact housing
Product Or Component Typemotion servo drive
Device Short NameLXM28S
[Us] Rated Supply Voltage220 V - 10...15 %)three phase || 220 V - 20...15 %)single phase
Network Frequency47.5...63 Hz
Type Of Cableshielded motor cable 0-55 ?C) copper
Discrete Input Logic, Discrete Output Logicpositive or negative CN1)
Height150 mm
Output Current 3S Peak, Output Current 3S Peak 2, Output Current 3S Peak 34.5 A 220 V
Electrical Isolationbetween power and control
Product Compatibilityservo motor BCH2 60 mm, 1 200 W
Status Led1 LED (Red) charge || 1 LED (Green) RUN || 1 LED (Red) error
Discrete Output Number4 logic output CN1)12...24 V DC || 1 pulse train output (PTO) CN1)
Discrete Input Voltage24 V DC logic
Transmission Rate9600 bauds...115200 bauds (automatic detection) 100-100 m
Discrete Output Voltage12...24 V DC
Discrete Input Number8 programmable CN1) || 2 fast capture CN1) || 1 safety function STO CN9)
Signalling Functionservo status and fault codes five 7-segment display units
MarkingCSA || cULus || CE
Connector TypeRJ45 CN3) || RJ45 CN4)
Phasethree phase || single phase
Net Weight1 kg
Communication InterfaceModbus, Integrated || SERCOS III, Integrated
Electrical Connectionspring terminal 0.82...1 mm?, AWG 18 L1-L2) || spring terminal 0.82...1 mm?, AWG 18 R, S, T) || spring terminal 0.82...1 mm?, AWG 18 U, V, W, PE) || spring terminal 0.82...1 mm?, AWG 18 PA/+, PBe)
Switching Frequency16 kHz
Type Of Coolingnatural convection
Supply Voltage Limits200-255 V three phase || 170-255 V single phase
Method Of Accessslave
Control Signal Typeservo motor encoder feedback CN2
Safety FunctionSTO (safe torque off), Integrated
Operating Positionvertical
Emc Filterwithout EMC filter
Maximum Leakage Current1.3 mA
Width55 mm
Overvoltage CategoryIII
Depth146 mm
Nominal Power0.2 kW 220 V 16 kHz
Continuous Output Current1.5 A 16 kHz
Continuous Power200 W 220 V
Supply Frequency50/60 Hz - 5...5 %
Rohs Exemption Information, Mercury Free, Pvc Free, Reach Free Of SvhcYes
Environmental DisclosureENVPEP1409001EN
Sustainable Offer StatusGreen Premium product
Reach RegulationFree of Substances of Very High Concern above the threshold
California Proposition 65 : WARNING: This product can expose you to chemicals includingLead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs RegulationX
Circularity ProfileENVEOLI1409001EN
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
Product CertificationscULus || CSA || CE
Ambient Air Temperature For Operation0-55 ?C
StandardsEN/IEC 61800-5-1
Electromagnetic Compatibilityconducted emission level 3category C3 EN/IEC 61800-3
Vibration Resistance3M4 3 mm 9-200 Hz)IEC 60721-3-3
Shock Resistance10 gn, type I IEC 60721-3-3
Ambient Air Temperature For Storage-25-65 ?C
Relative Humidity5-95 % without condensation
Ip Degree Of ProtectionIP20
