Invertek ODE-3-340240-3F42 11kW 15Hp 24A Output Current 380~480V 3Ph Input 380~480V 3Ph Output IP20 OptiDrive E3 Economy VFD
The ODE-3-340240-3F42 is produced by Invertek and is described as a Invertek ODE-3-340240-3F42 11kW 15Hp 24A Output Current 380~480V 3Ph Input 380~480V 3Ph Output IP20 OptiDrive E3 Economy VFD
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Label, Publisher, Studio | Invertek |
|---|---|
| CategoryL1 | Automation |
| CategoryL2 | Speed Controllers & VFDs |
| CategoryL3 | AC Vector Drives |
| CategoryL4 | Three Phase |
| DimensionUnit | inch |
| Extra Product Name | Invertek ODE-3-340240-3F42 11kW 15Hp 24A Output Current 380~480V 3Ph Input 380~480V 3Ph Output IP20 OptiDrive E3 Economy VFD |
| Voltage, Input voltage | 380/480V |
| Weight | 3.5 7.0547923840 |
| WeightUnit | lbs |
| Weight_Attrib | Packaged dimensions weight |
| depth, length | 6.9 |
| height | 10.3 |
| height_Attrib | Height |
| length_Attrib | Depth |
| moq, multiple, tierMinQty1 | 1 |
| MPN, PartNumber | ODE-3-340240-3F42 |
| qtyInStock | 0 |
| SKU | 6092689 |
| snippet | The ODE-3-340240-3F42 is produced by Invertek and is described as a Invertek ODE-3-340240-3F42 11kW 15Hp 24A Output Current 380~480V 3Ph Input 380~480V 3Ph Output IP20 OptiDrive E3 Economy VFD |
| tierPrice1 | 957.60 |
| width | 6.377952755905512 |
| width_Attrib | Packaged dimensions width |
| Frame, Phase, Drive dimensions size, Input phases | 3 |
| Height | 10.3 in 75 |
| Depth | 6.9 in |
| Rated power | 11 kW/15 HP |
| Width (in) | 5.2 |
| Supply fuse or MCB (type B) | 40 A |
| Packaged dimensions depth | 315 mm (12.4 in) |
| Supply current continuous | 27.5 A |
| Drive dimensions weight | 3.2 kg (7.05 lbs) |
| Max motor cable size, Max supply cable size | 8 mm? (0.01 in?) |
| Brake transistor | Internal brake transistor |
| Supply voltage | 380-480 V |
| Output current | 24 A |
| Drive dimensions fixings | 4 x M5 |
| Drive dimensions depth | 175 mm (6.89 in) |
| Packaged dimensions weight | 3.5 kg (7.72 lbs) |
| Max motor cable length | 100 m (328 ft) |
| Output voltage | 0 - supply voltage |
| Drive dimensions height | 261 mm (10.28 in) |
| EMC filter | Internal EMC filter |
| Display | LED |
| Packaged dimensions height | 254 mm (10 in) |
| Motor output rating | 11 kW (15 HP) |
| Drive dimensions width | 131 mm (5.16 in) |
| Enclosure | IP20 |
| Packaged dimensions width | 162 mm (6.38 in) |
| ASIN, Asin | B09ZBFLLQR |
| Brand | KlingerBorn |
| ProductCategoryId | 553958 601479011 lawn_and_garden_display_on_website |
| ProductGroup | Home Improvement |
| ProductTypeName | HOME_LIGHTING_ACCESSORY |
| Rank | 1113572 33942 5985 |
| Title | Optidrive E3 IP20 3Ph-380-480V, 11kW, 15HP, 24A, Filter C1, Brake Copper |
| URL | https://m.media-amazon.com/images/I/41RCo-BX27L._SL75_.jpg |
| Units | pixels pounds |
| Width | 75 |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| MRO Supply | 6092689 | 1 | 1 | 1 @ $957.60 | |
| ODE-3-340240-3F42 | 1 | -2 | 1 | 1 @ $957.60 | |
 vfds.com | ODE-3-340240-3F42 | 1 | 1 | 1 @ $1068.76 |
