Toa Electronics . M-864D CU

TOA M-864D CU Rack-mount Digital Stereo Mixer, 22 Input Channels and 6 Output Channels, Assignable Each Input to 6 Output Channels, Automatic Feedback Suppressor (FBS Function) Key Features - Equipped with 22 input channels (8 monaural inputs and 7 stereo inputs) and 6 output channels (4 monaural outputs and 1 stereo recording output) - Assignable each input to 6 output channels (OUTPUTs 1 – 4, REC OUT L/R) individually - Adjustable for intelligible sound output (ARC function) by automatically creating a sound field compensation filter (ARC filter) - Automatic feedback suppressor (FBS function) - Stereo inputs muted automatically by detecting the monaural input signal (Automatic Mute function) - Monaural inputs with a built-in analog gain control circuit (0 to +60 dB) - Monaural inputs capable of supplying phantom power (+24 V, 10 mA) - Stereo inputs with a built-in analog trim control circuit (–∞ to 0 dB) - Volume adjustable with 60 mm (2.36") faders - Each function settable at the M-864D using its front-mounted switches and faders - Advanced settings using the supplied M-864D PC Software via LAN - Designed for use in conjunction with the optional Remote Control Panels ZM-9011, ZM-9012, ZM-9013, and ZM-9014 (collectively referred to as "ZM Remote controller" in this manual), enabling volume control, channel ON/OFF, and Preset memory recall - UL certified Specifications - Power Source: 100 – 120V AC, 60Hz - Power Consumption: 30W - Frequency Response: 20Hz – 20kHz - Sampling Frequency: 48kHz - Dynamic Range: 100dB or more (IHF-A weighted) - Distortion: 0.03% or less, 1kHz, +4dB* input/output, 20Hz – 20kHz BPF - Crosstalk: -80dB or less, 1kHz - Preset Memory: 16 - Operating Temperature: 0 to 40ºC (32 to 104ºF) - Operating Humidity: 90 %RH (no condensation) - Dimensions: 19"W x 6.97"H x 6.19"D - Weight: 11.24 lb
