Contactor, Type L, multipole lighting, electrically held, 30A, 10 pole, 600 V, 110/120 VAC 50/60 Hz coil, NEMA 1 | Mayer Electric

Mayer Electric Supply . 8903LG1000V02C

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitmm
Extra Product NameContactor, Type L, multipole lighting, electrically held, 30A, 10 pole, 600 V, 110/120 VAC 50/60 Hz coil, NEMA 1 | Mayer Electric
UPC785901022145
depth, length153.0
height322.0
height_AttribHeight
jsonUrlData/Product/SQUARE-D-Contactor-Type-L-multipole-lighting-electrically-held-30A-10-pole-600-V-110-120-VAC-50-60-Hz-coil-NEMA-1-785901022145
jsonUrlData2937681cb-2065-46df-a8e0-abd2006137e8
length_AttribDepth
moq, multiple, tierMinQty11
MPN8903LG1000V02C
qtyInStock0
SKUSQD8903LG1000V02C
tierPrice11555.55
width198.0
width_AttribWidth
Range Of Product8903L
Control Circuitseparate control circuit
Product Or Component TypeElectrically Held Lighting Contactor
Warranty18 months
Local Signallingno indicator
Height322 mm
Control Typeselector switch HAND-OFF-AUTO)
[Uc] Control Circuit Voltage110 V AC 50 Hz || 120 V AC 60 Hz
Hold-In Power Consumption In Va35-35 VA 60 Hz || 35-35 VA 50 Hz
Electrical Connectionscrew-clamp terminals
Width198 mm
Depth153 mm
Line Rated Current20-20 A tungsten || 30-30 A fluorescent
Inrush Power In Va180-180 VA 60 Hz || 170-170 VA 50 Hz
Poles Description10P 10 NO
China Rohs RegulationPro-active China RoHS declaration (out of China RoHS legal scope)
Rohs Exemption Information, Mercury Free, Pvc Free, Toxic Heavy Metal Free, Reach Free Of SvhcYes
Environmental DisclosureENVPEP1407018EN
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectiveCompliant
Reach RegulationFree of Substances of Very High Concern above the threshold
California Proposition 65 : WARNINGCancer and Reproductive Harm - www.P65Warnings.ca.gov
Halogen Content PerformanceHalogen free plastic parts product
Product CertificationsUL Listed || CSA
Nema Degree Of ProtectionNEMA 1 painted sheet steel surface

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQD8903LG1000V02C111 @ $1555.55
