Harmony XB4, Single contact block, silver alloy, faston connector, 1 NO | Mayer Electric

SQUARE D . SQDZBE1013

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
Extra Product NameHarmony XB4, Single contact block, silver alloy, faston connector, 1 NO | Mayer Electric
UPC3389110816358
Weight0.011
WeightUnitkg
Weight_AttribNet Weight
jsonUrlData/Product/SQUARE-D-Harmony-XB4-Single-contact-block-silver-alloy-faston-connector-1-NO-3389110816358
jsonUrlData2542f0787-a643-4600-9244-aeea00592a5a
moq, multiple, tierMinQty11
MPN, SKUSQDZBE1013
qtyInStock0
tierPrice114.35
Connections - TerminalsFaston connector 1 x 6.35 mm || Faston connector 2 x 2.8 mm
Contacts Usagestandard contacts
Sale Per Indivisible Quantity5
Range Of ProductHarmony XB5 || Harmony XB4
Contact Operationslow-break
Contact Block Typesingle
Product Or Component Typecontact block
Device Short NameZBE
Ip Degree Of ProtectionIP20 IEC 60529
Warranty18 months
Mounting Of Blockfront mounting
Contacts Type And Composition1 NO
[Ui] Rated Insulation Voltage250 V 3)EN 60947-1
Operating Force2.3 N NO changing electrical state
Operating Travel2.6 mm NO changing electrical state) || 4.3 mm total travel)
Contacts Materialsilver alloy (Ag/Ni)
Mechanical Durability10000000 cycles
Positive Openingwithout
Net Weight0.011 kg
China Rohs RegulationX
Circularity ProfileENVEOLI1808008EN
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal Free, Reach Free Of SvhcYes
Environmental DisclosureENVPEP1808008EN
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
Reach RegulationFree of Substances of Very High Concern above the threshold
California Proposition 65 : WARNING: This product can expose you to chemicals includingDi-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Product CertificationsGL || CSA || UL || DNV || LROS (Lloyds register of shipping) || BV
Ambient Air Temperature For Operation, Ambient Air Temperature For Storage-40-70 ?C
StandardsEN/IEC 60947-5-4 || JIS C8201-5-1 || UL 508 || CSA C22.2 No 14 || EN/IEC 60947-1 || EN/IEC 60947-5-1 || JIS C8201-1
Shock Resistance30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Vibration Resistance5 gn 2-500 Hz)IEC 60068-2-6
Protective TreatmentTH

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDZBE1013111 @ $14.35
