ZETTLER AZ743-1CE-05DE | Relay: electromagnetic; DPDT; Ucoil: 5VDC; 10A; 10A/250VAC; PCB
ZETTLER AZ743-1CE-05DE | Relay: electromagnetic; DPDT; Ucoil: 5VDC; 10A; 10A/250VAC; PC
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer | ZETTLER |
|---|---|
| CategoryL1 | Relays and Contactors |
| CategoryL2 | Relays |
| CategoryL3 | Electromagnetic Relays |
| CategoryL4 | Miniature Electromagnetic Relays |
| Extra Product Name | ZETTLER AZ743-1CE-05DE | Relay: electromagnetic; DPDT; Ucoil: 5VDC; 10A; 10A/250VAC; PCB |
| atoms, moq, multiple | 1 |
| jsonUrlData | 5867a92da5653f6cbe91957e8f5ebc8b. |
| jsonUrlData2 | 195a1a11887f0a07af7e |
| keywords | ZETTLER, AZ743-1CE-05DE, AZ743-2CB-05DE |
| MPN | AZ743-1CE-05DE |
| qtyInStock | 0 |
| SKU | AZ743-2CB-05DE |
| snippet | ZETTLER AZ743-1CE-05DE | Relay: electromagnetic; DPDT; Ucoil: 5VDC; 10A; 10A/250VAC; PC |
| Type of relay | electromagnetic |
| Contacts configuration | DPDT |
| Rated coil voltage | 5V DC |
| Contact current max | 10A |
| AC contacts rating @R | 10A / 250V AC |
| DC contacts rating @R | 10A / 24V DC |
| Switched voltage | max. 150V DC, |
| Relay variant | miniature |
| Mounting | PCB |
| Coil resistance | 62? |
| Coil voltage min | 3.5V DC |
| Coil voltage max | 10.2V DC |
| Operate time | 7ms |
| Body dimensions | 29.5x13.2x16.2mm |
| Release time | 3ms |
| Coil power consumption | 196mW |
| Operating temperature | -40...100?C |
| Relay series | AZ743 |
| Contact resistance | 50m? |
| Terminal pitch | 5mm |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| AZ743-2CB-05DE | 1 | 1 |
