Mini circuit breaker, QO, 25A, 2 pole, 120/240VAC, 10kA, bolt on mount, 50 degrees C | Mayer Electric

Mayer Electric Supply . QOB22535

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitmm
Extra Product NameMini circuit breaker, QO, 25A, 2 pole, 120/240VAC, 10kA, bolt on mount, 50 degrees C | Mayer Electric
UPC785901620990
Weight0.268
WeightUnitkg
Weight_AttribNet Weight
depth, length74.0
height76.0
height_AttribHeight
jsonUrlData/Product/SQUARE-D-Square-D-QO-and-QOB-Miniature-Circuit-Breakers-QOB-Circuit-Breakers-QOB22535-785901620990
jsonUrlData2fa724904-375d-42f7-9730-abd20062e14c
length_AttribDepth
moq, multiple, tierMinQty11
MPNQOB22535
qtyInStock0
SKUSQDQOB22535
tierPrice1102.42
width38.0
width_AttribWidth
Circuit Breaker Applicationnot rated
Circuit Breaker Typestandard
Mounting Modebolt-on
Range Of ProductQO
Poles Description2P
Electrical Connectionpressure plate
Line Rated Current25 A
Product Or Component Typeminiature circuit-breaker
[Ue] Rated Operational Voltage120/240 V AC || 120 V AC || 48 V DC
Warranty18 months
Height76 mm
Breaking Capacity10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz || 5 kA 48 V DC
Tightening Torque4.6-4.6 N.m
Number Of Spaces Required2
Awg GaugeAWG 14...AWG 8 copper or aluminium
Width38 mm
Depth74 mm
Net Weight0.268 kg
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal FreeYes
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectiveCompliant
Reach RegulationReference contains Substances of Very High Concern above the threshold
Halogen Content PerformanceHalogen free product
Product CertificationsUL Listed || CSA
Ambient Air Temperature For Operation50 ?C

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDQOB22535111 @ $102.42
