NEMA Contactor, TeSys N, nonreversing, Size 1, 27A, 10HP at 460VAC, 3 pole, 3 phase, 24VDC coil, open | Mayer Electric

Mayer Electric Supply . T02CN13BD

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitinch
Extra Product NameNEMA Contactor, TeSys N, nonreversing, Size 1, 27A, 10HP at 460VAC, 3 pole, 3 phase, 24VDC coil, open | Mayer Electric
UPC785901878872
Weight1.28
WeightUnitlbs
Weight_AttribNet Weight
depth, length4.0
height3.34
height_AttribHeight
jsonUrlData/Product/SCHNEIDER-ELECTRIC-Contactor-TeSys-NEMA-Sz1-3P-24VDC-785901878872
jsonUrlData2906cfe06-500a-4125-9133-abd200633862
length_AttribDepth
moq, multiple, tierMinQty1, Nema Size1
MPNT02CN13BD
qtyInStock0
SKUSQDT02CN13BD
tierPrice1339.31
width1.76
width_AttribWidth
Range Of ProductTeSys N
Contactor Applicationnon-reversing
Product Or Component Typecontactor
Maximum Horse Power Rating7.5 hp 200 V AC || 7.5 hp 230 V AC || 10 hp 460 V AC || 10 hp 575 V AC
Product CertificationsUL Listed || CSA
Nema Degree Of Protectionnot rated (open device)
[Uc] Control Circuit Voltage24 V DC
Height3.34 in
Auxiliary Contact Composition1 NO + 1 NC
Poles Description3P
Line Rated Current27 A
Electrical Connectionscrew clamp terminals
Control Circuitcommon control circuit
Width1.76 in
Depth4.00 in
Phase3 phase
Net Weight1.28 lb(US)
[Ue] Rated Operational Voltage600 V AC
China Rohs RegulationPro-active China RoHS declaration (out of China RoHS legal scope)
Circularity ProfileENVEOLI1102029EN
Rohs Exemption Information, Mercury Free, Pvc Free, Toxic Heavy Metal Free, Reach Free Of SvhcYes
Environmental DisclosureENVPEP110229EN
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectiveCompliant
Reach RegulationFree of Substances of Very High Concern above the threshold
California Proposition 65 : WARNING: This product can expose you to chemicals includingAntimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDT02CN13BD111 @ $339.31
