JZ2-677H 2" Paper Cone Tweeter 12 Ohm

JZ2-677H 2" Paper Cone Tweeter 12 Ohm. Part Number: 289-2354 by Factory Buyouts.

Factory Buyouts . JZ2-677H

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, BrandFactory Buyouts
DimensionUnitinch
Extra Product NameJZ2-677H 2" Paper Cone Tweeter 12 Ohm
UPC848864048994
Weight0.2
WeightUnitlbs
depth, length0.9
diameter, height, width2.015
height_Attrib, width_AttribOverall Outside Diameter
length_AttribDepth
moq, multiple1
MPN, ModelJZ2-677H
qtyInStock0
SKU, Part Number289-2354
snippetJZ2-677H 2" Paper Cone Tweeter 12 Ohm. Part Number: 289-2354 by Factory Buyouts.
Unit of MeasureEach
Cone / Dome Diameter1.75"
Cutout Diameter2
Tweeter TypePaper Cone
Power Handling (RMS)15 Watts
Impedance12?
Frequency Response1,600 to 20,000Hz
Sensitivity92.6dB 2.83V/1m
Resonant Frequency (Fs)1559Hz
DC Resistance (Re)10.71?
Voice Coil Inductance (Le)0.096mH
Mechanical Q (Qms)2.79
Electromagnetic Q (Qes)9.99
Total Q (Qts)2.18
Overall Outside Diameter2.015"
Depth0.9"
