| Brand name, Manufacturer name, Manufacturer | Uniview |
|---|
| Condition | NEWCONDITION |
|---|
| DimensionUnit | m |
|---|
| Extra Product Name | Buy Uniview NVR302-32E2, 2 SATA Series 32-Chanel Network Video Recorder - Prime Buy |
|---|
| Weight | 1.8 |
|---|
| WeightUnit | lbs |
|---|
| Weight_Attrib | Weight (without HDD) |
|---|
| moq, multiple, tierMinQty1, RS485 | 1 |
|---|
| MPN, SKU | NVR302-32E2 |
|---|
| qtyInStock | 2 Weeks Factory Lead Time |
|---|
| tierPrice1 | 609.00 |
|---|
| width | 320.0 |
|---|
| width_Attrib | Incoming Bandwidth |
|---|
| IP Video Input | 32-ch |
|---|
| Two-Way Audio Input, Audio Output | 1-ch, RCA |
|---|
| Incoming Bandwidth, Outgoing Bandwidth | 320Mbps |
|---|
| Remote Users | 128 |
|---|
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS |
|---|
| Recording Resolution, Live View/Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
|---|
| Audio Compression | G.711A, G.711U |
|---|
| Synchronous Playback | 16-ch |
|---|
| Live View Display | 1/4/6/8/9/16/25/36 |
|---|
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
|---|
| Decoding Format | Ultra 265, H.265, H.264 |
|---|
| Capability | 1 x 12MP at 30, 2 x 4K at 30, 5 x 4MP at 30, 10 x 1080P at 30, 22 x 720P at 30, 32 x D1 |
|---|
| SATA | 2 SATA interfaces |
|---|
| Capacity | Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature) |
|---|
| eSATA, RS232 | NA |
|---|
| Disk Group | Support |
|---|
| VCA Detection by Camera | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking |
|---|
| VCA Search | Behavior Search, Vehicle Search |
|---|
| People Counting | People Flow Counting, Crowd Density Monitoring |
|---|
| Smart Intrusion Prevention (SIP), Vehicle Detection by Camera | Total 8-ch |
|---|
| General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Input Alarm, Audio Detection |
|---|
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal |
|---|
| Network Interface | 2 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces |
|---|
| USB Interface | Front panel: 1 x USB2.0, Rear panel: 1 x USB2.0 1 x USB3.0 |
|---|
| Alarm In | 8-ch |
|---|
| Alarm Out | 2-ch |
|---|
| Working Environment | -10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing) |
|---|
| Dimensions (WxDxH) | 380mm x 315mm x 53mm (15.0" x 12.4" x 2.1") |
|---|
| Weight (without HDD) | ≤1.8Kg (3.97lb) |
|---|
| Certification | CE, FCC, UL, RoHS, WEEE |
|---|
| CE | EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017 |
|---|
| FCC | Part15 Subpart B, ANSI C63.4 |
|---|
