BELDEN XX1348A 0021000 | Wire; CC Link; 3x20AWG; stranded; Cu; PVC; red; 305m; 300V
BELDEN XX1348A 0021000 | Wire; CC Link; 3x20AWG; stranded; Cu; PVC; red; 305m; 300
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer | BELDEN |
|---|---|
| CategoryL1 | Wires and Cables |
| CategoryL2 | Cables |
| CategoryL3 | Data Transmission Cables |
| CategoryL4 | Serial Bus Cables |
| DimensionUnit | mm |
| Extra Product Name | BELDEN XX1348A 0021000 | Wire; CC Link; 3x20AWG; stranded; Cu; PVC; red; 305m; 300V |
| atoms, moq, multiple | 1 |
| diameter, length, width | 7.7 |
| jsonUrlData | 3f715e0d7211f3a71cc7f4df371bd9f1. |
| jsonUrlData2 | 2cf554cf9013946bd78d |
| keywords | BELDEN, XX1348A 0021000, 1348A, Wires and Cables, Cables, Data Transmission Cables, Serial Bus Cables |
| length_Attrib, width_Attrib | Cable external diameter |
| MPN | XX1348A 0021000 |
| qtyInStock | 0 |
| SKU | 1348A |
| snippet | BELDEN XX1348A 0021000 | Wire; CC Link; 3x20AWG; stranded; Cu; PVC; red; 305m; 300 |
| Type of wire | data transmission |
| Cable application | CC Link |
| Core structure | stranded |
| Kind of core | Cu |
| Number of cores | 3 |
| Core diameter | 20AWG |
| Shield structure | Al-PET foil, |
| Wire insulation material | PVC |
| Insulation colour | red |
| Operating temperature | -30...60?C |
| Package contents | 305m |
| CPR standard | no classification |
| Cable external diameter | 7.7mm |
| Rated voltage | 300V |
| Kind of material | no flame propagation |
| Ground | tinned copper strand 22AWG |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| 1348A | 1 | 1 |
