Starter TeSys Hybrid Safe-Torque-Off 3kW-400V control 24VDC Spring | Mayer Electric

Mayer Electric Supply . LZ7H6X53BD

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitmm
Extra Product NameStarter TeSys Hybrid Safe-Torque-Off 3kW-400V control 24VDC Spring | Mayer Electric
UPC785901716259
Weight212
WeightUnitg
Weight_AttribNet Weight
depth, length114.5
height99.0
height_AttribHeight
jsonUrlData/Product/SCHNEIDER-ELECTRIC-Starter-TeSys-H-Safe-Torque-Off-3kW-400V-control-24VDC-Spring-785901716259
jsonUrlData20559807f-2352-4e56-9b0c-abd200627922
length_AttribDepth
moq, multiple, tierMinQty11
MPNLZ7H6X53BD
qtyInStock0
SKUSQDLZ7H6X53BD
tierPrice1388.49
width22.5
width_AttribWidth
Motor Starter Typedirect on line
[Uc] Control Circuit Voltage24 V DC
[Ue] Rated Operational Voltage500 V AC
[Ie] Rated Operational Current6.5 A 500 V AC-53A || 9 A 500 V AC-51 || 5 A 500 V AC-53A mounting side by side || 7 A 500 V AC-51 mounting side by side
Thermal Protection Adjustment Range1.5-9 A
Poles Description3P
Safety Reliability DataMTTFd = 517 years stop function || SFF = 99 % stop function || SFF = 99 % motor protection || MTTFd = 447 years motor protection || PFHd = 2.40E-9 1/h stop function
Product Or Component Typeultra-compact starter
Product NameTeSys Hybrid
Thermal Overload Classclass 10A IEC 60947-4-2
Maximum Horse Power Rating1 hp 200 V AC || 1.5 hp 230 V AC || 3 hp 460 V AC
Motor Power Kw1.5 kW 220 V AC 0.65 || 1.5 kW 230 V AC 0.65 || 2.2 kW 380 V AC 0.65 || 3 kW 400 V AC 0.65 || 3 kW 415 V AC 0.65 || 3 kW 440 V AC 0.65 || 3 kW 500 V AC 0.65
Device Short NameLZ7H
RangeTeSys
Safety LevelSIL 3 IEC 61508-1 stop function || PL = e ISO 13849-1 stop function || SIL 2 IEC 61508-1 motor protection
[Ui] Rated Insulation Voltage500 V AC 50/60 Hz
Height99 mm
Mounting Modeby clips
Maximum Operating Rate120 cyc/mn AC-51 50 % || 6 cyc/mn AC-53A 50 %
Auxiliary Contact Composition1 C/O fault signalling
Resetmanual || electrical reset
StandardsIEC 60947-4-2 || UL 60947-4-1
Mounting SupportDIN rail
Pollution Degree2
Control Circuit Voltage Limits19.2...30 V DC
CertificationsATEX as associated device for motor protection in zones 1 and 21 || cULus || CE
Width22.5 mm
Depth114.5 mm
Electrical Durability30 Mcycles
Net Weight212 g
[Uimp] Rated Impulse Withstand Voltage6 kV
Connections - Terminalsspring clamp terminals 1 0.2-2.5 mm? rigid || spring clamp terminals 1 0.25-2.5 mm? flexible - with cable end || spring clamp terminals 1 0.2-2.5 mm? flexible - without cable end
China Rohs RegulationX
Circularity ProfileENVEOLI1509013EN
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal Free, Reach Free Of SvhcYes
Environmental DisclosureENVPEP1509013EN
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectiveCompliant
Reach RegulationFree of Substances of Very High Concern above the threshold
California Proposition 65 : WARNINGCancer and Reproductive Harm - www.P65Warnings.ca.gov
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Ambient Air Temperature For Operation-25-30 ?C without derating || 30-70 ?C with derating
Ambient Air Temperature For Storage-40-80 ?C
Protective TreatmentTC
Ip Degree Of ProtectionIP20

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDLZ7H6X53BD111 @ $388.49
