FUJITSU NYP-24W-K-IE | Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 5A; 5A/250VAC; 120mW
FUJITSU NYP-24W-K-IE | Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 5A; 5A/250VAC; 120m
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer | FUJITSU |
|---|---|
| CategoryL1 | Relays and Contactors |
| CategoryL2 | Relays |
| CategoryL3 | Electromagnetic Relays |
| CategoryL4 | Miniature Electromagnetic Relays |
| Extra Product Name | FUJITSU NYP-24W-K-IE | Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 5A; 5A/250VAC; 120mW |
| atoms, moq, multiple, tierMinQty1 | 1 |
| jsonUrlData | c14bbc049d9c7ee392708877c517776f. |
| jsonUrlData2 | e984afa8d8e13bb9ecb9 |
| keywords | FUJITSU, NYP-24W-K-IE |
| MPN, SKU | NYP-24W-K-IE |
| qtyInStock | 392 |
| snippet | FUJITSU NYP-24W-K-IE | Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 5A; 5A/250VAC; 120m |
| tierMinQty2 | 5 |
| tierMinQty3 | 25 |
| tierMinQty4 | 100 |
| tierMinQty5 | 500 |
| tierPrice1 | 3.75 |
| tierPrice2 | 3.41 |
| tierPrice3 | 2.57 |
| tierPrice4 | 2.39 |
| tierPrice5 | 2.22 |
| Type of relay | electromagnetic |
| Contacts configuration | SPST-NO |
| Rated coil voltage | 24V DC |
| Contact current max | 5A |
| AC contacts rating @R | 5A / 250V AC |
| DC contacts rating @R | 5A / 30V DC |
| Switched voltage | max. 150V DC, |
| Relay variant | interface |
| Mounting | socket |
| Coil resistance | 4.8k? |
| Operate time | 10ms |
| Body dimensions | 22.9x5x17.5mm |
| Release time | 5ms |
| Coil power consumption | 120mW |
| Mechanical durability | 2000000 cycles |
| Operating temperature | -40...90?C |
| Relay series | NY |
| Contact resistance | 30m? |
| Electrical life | 100000 cycles |
| Contact material | AgNi |
| Terminal pitch | 7.62mm |
| Related items | JL-5N |
| Contact plating | gold-plated |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| NYP-24W-K-IE | 1 | 392 | 1 | 1 @ $3.75, 5 @ $3.41, 25 @ $2.57, 100 @ $2.39, 500 @ $2.22 |
