ADA Compliant, EPA Compliant, NSF Certified, WaterSense Labeled | Yes |
ANSI Specifications | ANSI A112.19.2, ANSI A117.1 |
Application | Commercial |
ASME Specifications | ASME A112.19.2 |
BAA Compliant, Built-In Grinder, CARB OTC LEED Compliant, GSA Approved, IAPMO Listed | No |
Basic Power Source | Battery |
Battery Life | 200,000 Cycles (4 Years @ 4,000 Cycles Per Month) |
Battery Type | Lithium |
Brand and Series | American Standard Selectronic |
Collection | Selectronic? |
Color Finish | Polished Chrome |
Color Finish Category | Chromes |
Connection Location, Spud Location | Top |
Depth, Length, Toilet Bowl Length | 4-1/2 in |
Exposed/Concealed, Installation | Exposed |
Faucet Connection | NPT |
Faucet Connection Size, Fitting Size 1, Fitting Sizes | 1 in |
Finish | Chrome |
Fixture Connection | Top Spud |
Fixture Type | Toilet, Closet \ Toilet |
Flow Rate | 1.1 GPF, 1.28 gpf |
Flow Rate Range | 1.0 gpf - 1.5 gpf |
Flush Action | Electronic |
Flush Mode | Double Flush |
Flush Type | Sensor |
Flush Valve Application | Commercial Toilet |
Gallons per Flush | 1.1/1.28 |
Green | WaterSense, Yes |
Height | 16-1/2 in |
Includes | 1" I.P.S. Angle Stop with Back-Flow Protection, Vandal-Resistant Cap, Sweat Solder Kit, Cover Tube, Wall Flange |
Inlet Size | 1" IPS |
Item | Automatic Dual Flush Valve |
Manufacturer | American Standard |
Manufacturers Warranty Length | 5 years |
Material | Alloy, Brass |
Maximum Pressure | 80 psi |
Package Quantity | 1 |
Part Number | 6065721.002 |
Power Source | 6V Lithium Battery |
Pressure Range | 20 to 125 psi |
Rough-In | 11-1/2" |
Sensor Range | 15-3/4 to 31-1/2" |
Series | Selectronic |
Size | 4-1/2 in x |
Spud Coupling | 1-1/2" |
Spud Size, Valve Size | 1-1/2 in |
Standards | ADA Compliant, ANSI/ASME 112.19.2, ASSE 1037 |
Toilet Rough-In | 11-1/2 in |
Valve Design | Piston |
