mpn:
brand:
manufacturer:
MPN:
Description:
HP: 1/3RPM: 58Volts: 115/230Amps: 7.2/3.6Hz: 60Phase: 1Frame: 42YEnclosure Type: TEFC (Totally Enclosed Fan Cooled)Mounting: SpecialShaft Diameter: 0.750"Shaft Length: 1.625"Motor Shell Length: 7.50"Overall Length: 14.57"Rotation: ReversibleService Factor: 1.0Maximum Ambient Temperature: 40? CInsulation Class: FDuty Cy
Attributes
| Key | Value |
|---|---|
| Amps | 7.2/3.6 |
| Duty Cycle | Continuous |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Frame | 42Y |
| HP | 1/3 |
| Hz | 60 |
| Insulation Class | F |
| Maximum Ambient Temperature | 40? C |
| Motor Shell Length | 7.50" |
| Mounting | Special |
| Overall Length | 14.57" |
| Phase | 1 |
| Rotation | Reversible |
| RPM | 58 |
| Service Factor | 1.0 |
| Shaft Diameter | 0.750" |
| Shaft Length | 1.625" |
| Ship Weight | 27 lbs. |
| Volts | 115/230 |
