TE Connectivity 5-102202-1

mpn5-102202-1
brandname: TE Connectivity
manufacturername: TE Connectivity

TE CONNECTIVITY 5-102202-1 Wire-Board Connector Header 4POS, 2.54MM

Brand: TE Connectivity
PartNumber: 5-102202-1
Model: 5-102202-1
PackageQuantity: 1
Manufacturer: TE CONNECTIVITY
Label: TE CONNECTIVITY

Attributes

Key	Value
Agency Approvals	CSA ; UL
Alternate Mfr Part Numb.	5-102202-1
Alternate Part No.	571-5-102202-1
Angle	Straight
Approved Standards	CSA LR7189, UL E28476
Brand	TE Connectivity
Category	Connectors, Interconnec.
Centerline (Pitch)	2.54?mm?[?.1?in?]
Color	Black
Connection Material	Brass
Connector	Printed Circuit Board
Connector Contact Load .	Fully Loaded
Connector Profile	Standard
Connector Terminates To	Printed Circuit Board
Connector Type	Male Pin
Contact Base Material	Brass
Contact Current Rating .	3
Contact Finish	Matte Gold Plated
Contact Finish - Mating	15.0?in (0.38?m)
Contact Finish - Post	Brass
Contact Finish Thicknes.	Tin
Contact Finish Thicknes.	-
Contact Gender	Pin (Male)
Contact Length - Mating	0.130" (3.30mm)
Contact Length - Post	0.589" (14.96mm)
Contact Material	Brass, Copper Alloy, Th.
Contact Mating Area Pla.	Gold
Contact Mating Area Pla.	15
Contact Plating	Gold Over Nickel, Gold
Contact Plating Thickne.	15 ?in
Contact Shape	Square, Gold
Contact Type	0.100" (2.54mm), Pin
Contact Underplating Ma.	Nickel
Current Rating	3 A
Current Rating (Amps)	-
Family Name	AMPMODU Interconnect Sy.
Fastening Type	0.240" (6.10mm)
Features	-65?C ~ 105?C, With Boa.
Flammability Rating	UL 94 V-0
Header Type	Shrouded
Hole Center to Center	2.54 mm
Housing Color	Black
Housing Material	Thermoplastic
Ingress Protection	UL94 V-0
Insulation Color	3A
Insulation Height	Square
Insulation Material	-
Insulation Resistance	5000 MOhms
Item	PCB Mount Header
Manufacturer	TE Connectivity
Manufacturer Part No.	5-102202-1
Mated Stacking Heights	100.0?in (2.54?m)
Material	Thermoplastic
Material Flammability R.	Black
Mating Alignment	With
Mating Alignment Type	Polarization
Mating Post Length	6.1 mm
Max. Temp.	105?C
Mfr	TE Connectivity AMP Con.
Mounting Angle	Vertical
Mounting Hole Size	0.035 in
Mounting Type	Solder
Number of Contacts	4
Number of Positions	1, 4
Number of Positions Loa.	Board to Board or Cable
Number of Rows	1, -
Operating Temperature	-55 to +105 ?C, -
Operating Temperature R.	-65 ? 105, - 55 C to + .
Overall Contact Length	0.549" (13.94mm)
Overall Length	0.52 "
Package	Active
Package Quantity	1
Packaging Method	Tube
Packaging Quantity	40
Panel Mount Feature	Without
Part Status	Header
PCB Connector Assembly .	PCB Mount Header
PCB Contact Termination.	Tin
PCB Contact Termination.	Matte
PCB Mount Orientation	Vertical
PCB Mount Retention	Without
PCB Thickness (Recommen.	1.4?mm?[?.055?in?]
Pin Length	0.13 "
Pin Spacing	0.1 in
Pitch	2.54 mm (0.100?), 2.54 .
Pitch - Mating	4
Primary Type	Board Mount
Product Category	Headers & Wire Housings
Product Header	MOD II Shrouded Type Co.
Product Type	Headers
Row Spacing	2.54 mm
Row Spacing - Mating	All
Row-to-Row Spacing	2.54?mm?[?.1?in?]
Series	Tube, AMPMODU Mod II Se.
Shrouding	Through Hole
Special Features	Breakaway
Standards	UL E28476; CSA LR7189
Style	Shrouded - 4 Wall
Terminal Finish	Tin Plated; Matte Tin O.
Terminal Type	Through Hole
Termination	Through Hole, Push-Pull
Termination Method to P.	Through Hole - Solder
Termination Post	3.3?mm?[?.13?in?]
Termination Post Length	3.3 mm
Termination Style	Through Hole
Tradename	AMPMODU
Type	Vertical Header, Shroud.
UL Flammability Rating	UL 94V-0
Voltage Rating	-

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Preferred Tier
us.rs-online.com	70042624	0.56713	1	1166		TE Connectivity	0.56713 @ 10
Onlinecomponents.com	5-102202-1	1.0	1	15761		TE Connectivity / AMP Brand	1.0 @ 10
Waldom	TE CONNECTIVITY AMP BRAND 5-102202-1	1.0	80	189		TE CONNECTIVITY/AMP BRAND	1.0 @ 80
Avnet	5-102202-1	1.185	1	4860		TE Connectivity	1.185 @ 10
Newark	87K2237	1.22	1	1254		AMP - TE CONNECTIVITY	1.22 @ 10
Digi-Key	A32551-ND	1.389	1	10		TE Connectivity AMP Connectors	1.389 @ 10
swatee.com	5-102202-1	1.88	1	1395		TE Connectivity	1.88 @ 10
RS Delivers	864-0726	1.944	1	10		TE Connectivity	1.944 @ 10
TE Connectivity	5-102202-1	3.71258	1	168		TE Connectivity (TE)	3.71258 @ 10
AmazonTP	B07KWGLV17	27.76	1	10	2	TE Connectivity / AMP Brand	27.76 @ 10
Zoro	G300939526	132.0	1	10		Te Connectivity	132.0 @ 10
