Schneider Electric HDL26110

B00CONO85Y

SCHNEIDER ELECTRIC HDL26110 Molded Case Circuit Breaker 600-Volt 110-Amp Electrical Box

SCHNEIDER ELECTRIC HDL26110 Molded Case Circuit Breaker 600-Volt 110-Amp Electrical Boxzoom

Attributes

Key Value
[Ics] Rated Service Bre.25 kA 220/240 V AC 50/6.
[Ue] Rated Operational .690 V AC 50/60 Hz IEC 6.
[Ui] Rated Insulation V.750 V IEC 60947-2
[Uimp] Rated Impulse Wi.8 kV IEC 60947-2
Ambient Air Temperature.-2-70 ?C
Ambient Air Temperature.-50-85 ?C
Amperage Rating110, 110, 110 A
Awg GaugeAWG 14...AWG 3/0 alumin.
BrandSquare D by Schneider E.
Breaking Capacity25 kA 240 V AC 50/60 Hz.
Breaking Capacity CodeD
California Proposition .DINP, which is known to.
Catalog NumberHDL26110
China Rohs RegulationProduct out of China Ro.
Circularity ProfileENVEOLI1311006EN
ColorBlack
Communication InterfaceModbus || Ethernet
ConnectionAWG 14...AWG 3/0 ALUMIN.
Connection typeLine/Load Lug
Continuous Current Rati.80 %
Control Typetoggle
Country of OriginMexico
Depth86 mm
Device Applicationdistribution
Dimensions4.36 in L x 2.74 in W x.
Electrical Connectionlugs line || lugs load
Enclosure TypeNEMA AB1
Environmental DisclosureENVPEP1311006EN
Eu Rohs DirectiveCompliant
FrameD
Frequency Rating50/60, 50/60 Hz
Height163 mm, 6.42
Interrupt Rating18/14/20/25, 18/14/20/2.
Ip Degree Of Protectionfront cover IP40 IEC 60.
Item Typecircuit breaker
Length4.36 IN
Line Rated Current110-110 A
Local Signallingswitched off (OFF) 1 tr.
Made in USANo
Magnetic Hold Current900 A
Magnetic Tripping Curre.1700-1700 A
ManufacturerSchneider Electric
Mercury FreeYes
Mounting Modeunit mount lug)
Mounting Supportlug
Mounting typeSurface
Net Weight2.2 kg
Network Frequency50/60 Hz
Number of Poles2
Number Of Slots2 auxiliary switch OF p.
Operating Temperature40 A Degrees C
Phase1
Poles Description2P
Pollution Degree3 IEC 60947-1
Product CertificationsUL || CSA || NOM
Product NamePowerPact H
Product Or Component Ty.circuit breaker
Protected Poles Descrip.2t
Pvc FreeYes
Quality LabelsCE
Quantity Per Set1
RangePowerPact
Reach RegulationReference contains Subs.
Rohs Exemption Informat.Yes
Special FeaturesUNIT MOUNT
StandardUL LISTED-CE-IEC-CSA
StandardsUL || CSA || NEMA || NO.
Suitability For Isolati.yes IEC 60947-2
Sustainable Offer StatusGreen Premium product
Temperature Rating (Deg.40, 40 deg C
Terminal IdentifierAL150HD
Tightening Torque5-5 N.m 2.5-6 mm? (AWG .
Trip Range110 A,1700 A,900 A, 900.
Trip Typethermal-magnetic, Therm.
Trip Unit Technologythermal-magnetic
TypeType HDL
UPC785901578376
Utilisation Categorycategory A
Voltage Rating250 V DC-600 V AC, 600 .
Warranty18 months
Warranty DescriptionContractual Warranty:18.
Width104 mm, 4.09
Wire Size14 to 3/0 AWG Al/Cu
Wire Stripping Length16 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Newark33M90222205.391In StockSQUARE D BY SCHNEIDER ELECTRIC2205.39 @ 1
thumbzoomstandardelectricsupply.com22923682549.411In StockSquare D (Schneider Electric)2549.41 @ 1
thumbzoommayerelectric.comSQDHDL261102667.21In StockSQUARE D4.842667.2 @ 1
thumbzoomgordonelectricsupply.comHDL261102730.01In Stock10SQUARE D2730.0 @ 1
thumbzoomRadwellHDL261102850.01In StockSCHNEIDER ELECTRIC SQUARE D2850.0 @ 1
thumbzoomcrescentelectric.com6010384105.51In StockSquare D by Schneider Electric4105.5 @ 1
