TE Connectivity 7-215079-6

B01LPSFW2G

TE CONNECTIVITY 7-215079-6 Micro-MaTch 6 Position 1.27 mm Pitch Female on Board Connector - 250 item(s)

TE CONNECTIVITY 7-215079-6 Micro-MaTch 6 Position 1.27 mm Pitch Female on Board Connector - 250 item(s)zoom

Attributes

Key Value
Alternate Mfr Part Numb.7-215079-6
Alternate Part No.571-72150796
AngleVertical
ApplicationsAutomotive, General Pur.
Base Product Number215079
BrandTE Connectivity
CategoryConnectors, Interconnec.
Centerline (Pitch)1.27?mm?[?.05?in?]
Circuit ApplicationSignal
ConnectorPrinted Circuit Board, .
Connector Height4?mm?[?.16?in?]
Connector ProfileStandard
Connector SystemBoard-to-Board
Connector TypeReceptacle
Contact Base MaterialPhosphor Bronze
Contact Current Rating .1
Contact Finish - MatingTin
Contact Finish - PostTin
Contact Finish Thicknes.-
Contact Finish Thicknes.-
Contact GenderSocket (Female)
Contact Length - Post0.122" (3.10mm)
Contact MaterialPhosphor Bronze
Contact Mating Area Pla.Tin
Contact Mating Area Pla.3 ? 5??m?[?118.11 ? 196.
Contact PlatingTin
Contact Shape-
Contact TypeForked, Pin
Contact Underplating Ma.Nickel
Country of Origin (subj.Germany
Current Rating (Amps)-
DescriptionCONN RCPT 6POS 0.1 TIN .
Detailed Description6 Position Receptacle C.
Digi-Key Part NumberA30729TR-ND - Tape & Re.
Fastening TypePush-Pull
Features-
Header TypeShrouded
Housing ColorRed
Housing MaterialPolyester, Polyester - .
Ingress Protection-
Insulation ColorRed
Insulation Height0.157" (4.00mm)
Insulation MaterialPolybutylene Terephthal.
ManufacturerTE Connectivity AMP Con.
Manufacturer Part No.7-215079-6
Manufacturer Product Nu.7-215079-6
Manufacturer Standard L.45 Weeks
Mated Stacking Heights-
Material Flammability R.UL94 V-0
Mating AlignmentWithout
Mating Entry LocationTop
Mating RetentionWithout
MfrTE Connectivity AMP Con.
Mounting TypeThrough Hole
Number of Contacts6
Number of Positions6
Number of Positions Loa.All
Number of Rows2
Operating Temperature-40?C ~ 105?C
Operating Temperature R.-40 ? 105
PackageTape & Reel (TR)
Packaging MethodBox & Carton
Packaging Quantity250
Panel Mount FeatureWithout
PCB Contact Termination.Tin
PCB Mount AlignmentWithout
PCB Mount OrientationVertical
PCB Mount RetentionWith
PCB Mount Retention TypeKinked Solder Tails
Pitch1.27 mm (0.050"), 1.27 .
Pitch - Mating0.100" (2.54mm)
Primary TypeBoard Mount
Product CategoryHeaders & Wire Housings
Product StatusActive
Row Spacing - Mating0.100" (2.54mm)
Row-to-Row Spacing1.5
SeriesMicro-MaTch Series, Mic.
StyleBoard to Board or Cable
TerminationSolder, Kinked Pin, Sol.
Termination Method to P.Through Hole - Solder
Termination Post3.1?mm?[?.122?in?]
Termination StyleThrough Hole
TypeReceptacle
UL Flammability RatingUL 94V-0
Voltage Rating100VDC

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
WaldomTE CONNECTIVITY AMP BRAND 7-215079-60.5725013750TE CONNECTIVITY/AMP BRAND0.57 @ 250
Future Electronics58553820.67225014250TE Connectivity0.672 @ 250
HotendaH14176560.724250138TE Connectivity AMP Connectors0.724 @ 250
Onlinecomponents.com7-215079-60.75940701TE Connectivity0.759 @ 40
thumbzoomZoroG1010697430.81250123Te Connectivity0.81 @ 250
thumbzoomTME7-215079-60.86250250TE Connectivity0.86 @ 250
us.rs-online.com700859980.882500113TE Connectivity0.88 @ 2500
TE Connectivity7-215079-61.0353516144TE Connectivity (TE)1.03535 @ 1
thumbzoomNewark31C73091.13116097AMP - TE CONNECTIVITY1.13 @ 1
thumbzoomDigi-Key7403761.34172840TE Connectivity AMP Connectors1.34 @ 1
RS Delivers341-76751.561211850TE Connectivity1.5612 @ 1
thumbzoomswatee.com7-215079-61.61661TE Connectivity1.6 @ 1
AmazonTPB01LPSFW2G232.1811235TE CONNECTIVITY232.18 @ 1
AmazonSCB01LPSFW2G232.181123TE+Connectivity232.18 @ 1
