Alpha Wire 1292C SL001

B00KSULEFW

Alpha Wire Part Number 1292C SL001

Alpha Wire Part Number 1292C SL001zoom

Attributes

Key Value
Alternate Part No.602-1292C-1000
ApplicationFor communication and c.
BrandAlpha Wire
Cable TypeMulti-Conductor
Conductor MaterialTinned Copper (TC)
Conductor Size22 AWG
ConfigurationConductors
Delivery RestrictionsDue to size or weight o.
FeaturesConductor: Stranded Tin.
Insulation MaterialPolyvinyl Chloride (PVC)
Insulation Thickness0.010 in.
Jacket ColorGray, Slate
Jacket ColourGray
Jacket MaterialPVC, Polyvinyl Chloride.
Jacket Thickness0.032 in.
Length12, 1000 ft
ManufacturerAlpha Wire
Manufacturer Part No.1292C SL001
Maximum Operating Tempe.75 ?C
Number of Conductors2
Outer Diameter0.17 in.
Outside Dia.0.168 in
Outside Diameter4.32 mm
Package Quantity1
PackagingCoil
Product CategoryMulti-Conductor Cables
Product HeaderMulticonductor Foil Shi.
Series1292 Series, 1292
ShieldAluminum/Polyester Foil
Shield MaterialAluminum/Polyester Tape
ShieldingShielded, Foil
StandardsCSA CMG; CSA FT4; UL AW.
Stranding7x30, 7 x 30
Temperature, Rating-20 to 80 C
TypeCommunication and Contr.
Unit Weight7.661 kg
Voltage300V
Voltage Rating300 V
Wire Gauge - AWG22
Wire Size22 AWG

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
RS Delivers187-19011.239611000Alpha Wire1.2396 @ 1000
thumbzoomalldataresource.comA1292C-ALT1.3911000Alpha Wire1.39 @ 1000
thumbzoomAI Consolidated1292C-SL001-ALPHA-WIRE456.111000Alpha Wire16.894456.1 @ 1000
absupply.netALPHA WIRE CMP. 1292C SL001469.3711000Alpha Wire469.37 @ 1000
thumbzoomZoroG1169753487.9911000Alpha Wire487.99 @ 1000
AmazonTPB00KSULEFW503.08110002Alpha Wire503.08 @ 1000
us.rs-online.com70137538606.5711000Alpha Wire606.57 @ 1000
thumbzoomswatee.com1292C SL001612.5611000Alpha Wire612.56 @ 1000
thumbzoomNewark92F6768655.2711000ALPHA WIRE655.27 @ 1000
